XSF-9 inverted biological microscope
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
| Parts | Specification | XSF-9 | XSF-9PH |
| Main Body |
Including left & right hand plate,
four M4 screws, one screwdriver |
● | ● |
| Total Magnification | 100X-400X | ● | / |
| 40X-640X | ● | ||
| Eyepiece | Wide field ?WF10x/20 | ● | ● |
|
Wide field WF10x/18,
with micrometer 0.1mm |
/ | ● | |
| Wide field ?WF16x/13mm | / | ● | |
| Viewing Tube |
Compensation binocular head,
45° inclined, interpupillary distance 50-75mm |
/ | / |
|
Compensation trinocular head,
45° inclined, interpupillary distance 50-75mm |
● | ● | |
| Nosepiece | 4 Holes revolving nosepiece | ● | ● |
|
Long working
Distance Plan objective |
LPL2.5X/0.07，W.D.=29.7mm | / | / |
| LPL4X/0.10，W.D.=17.5mm | / | ● | |
| LPL10X/0.25，W.D.=7.9mm | ● | ||
| LPL25X/0.40，W.D.=5.0mm | ● | ● | |
| LPL40X/0.65，W.D.=3.0mm | ● | ● | |
|
Long working
distance Plan phase contrast objective |
LPL Ph+ 10X/0.25，W.D.=7.9mm | ● | |
| LPL Ph+ 25X/0.40，W.D.=5.0mm | ● | ● | |
| LPL Ph+ 40X/0.65，W.D.=3.0mm | ● | ||
| Focusing System |
Coaxial coarse & fine focusing knob,
with rack stop, coarse focusing range 22mm, fine focusing graduation 0.002mm |
● | ● |
| Stage |
Fixed stage, with specimen clip,
size 170x195mm |
● | / |
|
Mechanical stage, size 170x195mm,
moving range 71x78mm, minimum scale 0.1mm, with specimen plate, culture dish plate. |
/ | ● |
