O-I3 Inverted Biological Microscope
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
| Item | O-I3 | O-I3PH | ||
| Main Body | ● | ● | ||
| Eyepiece | WF10×／20mm | ●● | ●● | |
| WF16×／13mm | ○○ | ●● | ||
| 10X Article Eyepiece (0.1mm) | ○ | ● | ||
| Centering Eyepiece | ● | ● | ||
| LWD Plan Objective | LPL 2.5×／0.07 | W.D.=29.7mm | ○ | ○ |
| LPL 4×／0.10 | W.D.=17.5mm | ○ | ● | |
| LPL10×／0.25 | W.D.=7.9mm | ● | ○ | |
| LPL25×／0.40 | W.D.=5.0mm | ● | ● | |
| LPL40×／0.65 | W.D.=3.0mm | ● | ● | |
|
LWD Plan
Phase Contrast Objective |
LPL Ph+ 10×／0.25 | W.D.=7.9mm | ○ | ● |
| LPL Ph+ 25×／0.40 | W.D.=5.0mm | ● | ● | |
| LPL Ph+ 40×／0.65 | W.D.=3.0mm | ○ | ● | |
| Annular Spot 10X | ○ | ● | ||
| Annular Spot 25X | ● | ● | ||
| Annular Spot 40X | ○ | ● | ||
| Slide Relief Phase Contrast Condenser N.A.0.35 W.D. =45mm | ● | |||
| Turnable Relief Phase Contrast Condenser N.A.0.35 W.D. =45mm | ● | |||
|
Seidentopf Trinocular Head: Inclined 45° Both 100 (binocular tube) : 0 (photo tube) and 20 (binocular tube) : 80 (photo tube) |
● | ● | ||
|
Mechanical stage available for 96 holes plate,
moving range: 128（X）×80（Y）mm Large Stage: 206 (X) X 170 (Y) mm |
● | ● |
