IBE-1000 Inverted Biological Microscope
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
| Items | IBE1000 | Order No. |
| 10× WF eyepiece FN＝20 | ●● | EW10 |
| 16× WF eyepiece FN＝14 | ●● | EW16 |
| 10× plan reticle eyepiece FN＝18 | ● | EPr10b |
| Centering eyepiece | ● | ECi |
| 2.5× long working distance objective NA＝0.07; WD =28.89 | ○ | B-OLPr2.5 |
| 4× long working distance objective NA＝0.10 ;WD=16.50 | ○ | B-OLPr4 |
| 10× long working distance objective NA＝0.25; WD=7.90 | ● | B-OLPr10 |
| 25× long working distance objective NA＝0.40; WD=5.00 | ● | B-OLPr25 |
| 40× long working distance objective NA＝0.65; WD=3.00 | ● | B-OLPr40 |
|
10× long working distance positive phase contrast objective
NA＝0.25 ; WD=7.90 |
● | B-OLPpr10 |
|
25× long working distance positive phase contrast objective
NA＝0.40 ;WD=5.00 |
● | B-OLPpr25 |
|
40× long working distance positive phase contrast objective
NA＝0.65 ;WD=3.00 |
● | B-OLPpr40 |
|
10× long working distance negative phase contrast objective
NA＝0.25 ;WD=7.90 |
○ | B-OLPnr10 |
|
25× long working distance negative phase contrast objective
NA＝0.40 ; WD=5.00 |
○ | B-OLPnr25 |
|
40× long working distance negative phase contrast objective
NA＝0.65 ;WD=3.00 |
○ | B-OLPnr40 |
| long working distance phase contrast condenser NA＝0.30;WD=55.00 | ● | C15 |
| Mechanical stage: size:238×160; moving range: 50×50 | ● | S28 |
| Sliding trinocular head, Inclined 45°, Interpupilary Distance: 55-75mm | ● | 18X.30 |
| Photography tube group | ○ | MP04 |
| Photography adaptor | ○ | TV04 |
| Digital Photography device (CU43-2+DV02+camera) | ○ | / |
| 0.01mm micrometer | ○ | / |
