XDS-41 inverted biological microscope

Minimum Order
1
Packaging
N/A
Delivery
15 Days
Item XDS-41
Frame One-piece construction from arm to base,with flourescence excitation interface
UCIS Infinity Independent Achromatic Optical Design
With digital camera joint on the left side
Co-axial coarse and fine focusing knob,precision:0.001mm
Wide voltage:100∽240V,47/63Hz
Seidentopf

Observation Tube

Trnocular Tube, Interpupillary distance

50-75mm,45°inclined,diopter adjustable.

Split ratio: 50:50

Eyepiece WF10X/22 (reticle optional) ●●
WF15X/16 (reticle optional) ○○
Infinity Plan

Objectives

4X,10X,20X,40X,60X
Infinity Phase

Contrast Plan

Objectives

4X,10X,20X,40X
Infinity Plan

Florescent

Objectives

4X,10X,20X,40X,60X
Infinity Semi-apo

Plan Florescent

Phase contract

Objectives

20X,40X
Fixed Stage Size: 215(W)×250(L)mm

Could mount the Stage extension board and attachable mechanical stage.

Size of stage extension board: 120(W)×80(L)mm
