LAP Low Abrisive Slurry Pump

LAP Low Abrisive Slurry Pump

Main Specifications

Size: 1-30 inches

Capacity: 25-13860 m3/h

Head: 5-60m

Material: Hi-chromium metal liner, or Rubber liner

Seal: Packing seal, Expeller seal

Pump Features

1. The LAP pump is a horizontal cantilever centrifugal pump with double casing structure, which is Wholly exchangeable with L & LR series Warman pump. The pumps are suitable for the transportation of slurry of low abrasion and concentration. The shaft seal of this pump used soft packing seal or centrifugal expeller seal. This pump has a high rotation speed, and required less installation area. The pump inner casing is made of replaceable anti-wearing metal liner or rubber liner, and the impeller is also made of anti-wearing metal alloy or rubber material. Our pump’s discharge has 8 positions at every 45-degree interval that can be selected to meet the customer installation and application requirements.

2. The bearing assembly is with bracket structure. It makes much easier to adjust the clearance of the impeller and the suction plate and easily disassembling the pump. The bearing is using grease lubrication.

3. Drive methods: the pump and motor could be used direct coupling (DC) drive, or with belts and pulley drives. When use pulley drives, there different installation methods, such as CV, CR, CL and ZV drives. It could be selected according to the room space and motor power, to meet the customer requirement.

Pump Code Explanation

Pump Structure

1. Inlet rubber seal 2. Pump cover 3. Suction bush 4.Volute liner seal 5.Volute liner

6. Outlet rubber seal 7. Impeller 8. Frame plate liner insert 9. Stuffing box 10. Shaft sleeve

11. Soft packing gland 12. Bearing assembly 13. Shaft
