Wellon batch program programmer SP108

Programmer hardware features
■ Dimensions: 21916934mm, net weight: 580g;
■ Power Specifications: Input AC 100-220V
■ Standby current: <200 mA; operating current: 250-350mA
■ Dual working mode, online support mode (USB interface) and offline mode (local LCD, keyboard)
■ Offline programming, each programmer can use a built-in chip to store programming files, no need to connect to a computer, easy to carry to a variety of sites, flexible use.
■ It supports LCD and Chinese English.
■ Data security, using new encryption technology, the encrypted program data is stored in the built-in chip, effectively preventing data leakage
■ USB2.0 interface, download speed is fast.
■ The device algorithm completely implements by software, and the USB interface has an automatic online upgrade function to protect the user’s investment interests effectively.
■ There is a complete overcurrent protection circuit that will not damage the programmer due to short circuit of the chip.
■ Built-in high-speed microcontroller to automatically verify data to ensure system reliability. Up to eight chips can program at the same time.

Programmer software features
■ Support Simplified Chinese, Traditional Chinese, English, Italian, Dutch, Korean, Polish, Portuguese, Turkish, Hungarian ten languages.
■ The chip data is extremely detailed, including package drawings, chip model nomenclature and adapter data.
■ The manufacturer logo is provided in the chip selection to help users find the chip more clearly and quickly.
■ Chinese and English online help system for user convenience.
■ The file format is automatically recognised.
■ The programming parameters can be modified to determine the programming parameters according to the specific conditions of the chip.
■ Counts chips that have successfully programmed. Reset the count value while offline.
■ The programmer can pre-install up to 64 project files.
■ The access password can be set to ensure the security of user data.
■ The device selected with “Offline Mode” selected when the method that can be programmed for download and can download to the programmer. Otherwise, it is a device that can only process with a single device. The device is greyed out on the socket in the lower right corner when programming a single device.
