performance
Measuring range
0.2 m...30 m, 90% response rate 1) 2)
0.8 m...15 m, remission rate 6% 1) 2)
Target natural object
The resolution is 12 digits
Repeatability 1mm 3) 4)
Accuracy ±3 mm
Response time 250 ms
The output time is 250 milliseconds
Light source laser, red 5)
Laser class 2, in accordance with 21 CFR 1040.10 and 1040.11, except within the tolerances of notice no. 50 laser issued on 24 June 2007 (IEC 60825-1:2014, EN 60825-1:2014)
Typical value spot size (distance)
10 mm (at 7 m)
45 mm (at 30 m)
100 mm (at 70 m)
1) under ambient light, the maximum is 1 KLX constant light.
2) maximum 150m.
3) 6%...90% remission.
4) statistical error: 1.
5) at T A = +25°C, the average service life is 50,000 h.
