GLL170-N334

Type stand-alone version

Dimensions (width x height x depth) 10 mm x 31.7 mm x 72.5 mm

Case design (glow) rectangle

Maximum induction range

0 mm...190 mm, close to system 1) 2)

0 mm...800 mm, sparring system 3)

Sensing range

0 mm...160 mm, close to system 1) 2)

0 mm...700 mm, light transmission system 3)

The type of light is red

Light source LED 4)

The wavelength is 632 nanometers

Adjust potentiometer, 8 turns 5)

Delay time can be selected by rotating switch, 0 ms...40 ms

Function of time

No time lag

Close the delay

Indication led

Status indicator
