RF Duplexer / Triplexer / Microwave Duplexer
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
RF Microwave Components Factory Customized
1 to 3W Reverse Power
| Model No. | Freq.Range (MHz) | IL. (dB) | Isolation (dB) | VSWR | Power (W) | Connector Type | Temp. (°C) | Dimension LxWxH(mm) | |
|---|---|---|---|---|---|---|---|---|---|
| UIYDX19383A | TX | 380~395 | 1.5 | 70 | 1.4 | 100 | N, SMA | -30~+70 | 193×83×68 |
| RX | 450~470 | ||||||||
| UIYDX155118A | TX | 436.5~443.5 | 2.0 | 65 | 1.3 | 100 | N, SMA | -30~+70 | 155×118×65 |
| RX | 453~460 | ||||||||
| UIYDX342174A | TX | 448.2~454.8 | 1.5 | 60 | 1.3 | 50 | N, SMA | -30~+70 | 342×174×69 |
| RX | 463.2~469.8 | ||||||||
| UIYDX151151A | TX | 699~716 | 1.5 | 75 | 1.22 | 100 | N, SMA | -30~+70 | 151×151×44 |
| RX | 729~746 | ||||||||
| UIYDX187151A | TX | 703~748 | 1.5 | 60 | 1.22 | 100 | N, SMA | -30~+70 | 187×151×44 |
| RX | 758~803 | ||||||||
| UIYDX151151B | TX | 791~821 | 1.5 | 65 | 1.22 | 100 | N, SMA | -30~+70 | 151×151×44 |
| RX | 832~862 | ||||||||
| UIYDX151151C | TX | 814~849 | 1.5 | 65 | 1.22 | 100 | N, SMA | -30~+70 | 151×151×44 |
| RX | 859~894 | ||||||||
| UIYDX201162A | TX | 880~915 | 1.5 | 70 | 1.5 | 100 | N, SMA | -30~+70 | 201×162×45 |
| RX | 925~960 | ||||||||
| UIYDX11880A | TX | 1350~1518 | 1.0 | 60 | 1.4 | 50 | N, SMA | -55~+85 | 118×80×43 |
| RX | 1625~1785 | ||||||||
| UIYDX100120A | TX | 1350~1518 | 0.5 | 40 | 1.4 | 250 | N, SMA | -55~+85 | 100×120×38 |
| RX | 1625~1785 | ||||||||
| UIYDX121175A | TX | 1662 | 3.0 | 50 | 1.3 | 50 | N-F | -30~+70 | 121×175×35 |
| RX | 1667 | ||||||||
| UIYDX102102A | TX | 1710~1785 | 2.0 | 60 | 1.5 | 100 | N, SMA | -30~+70 | 102×102×29 |
| RX | 1805~1880 | ||||||||
| UIYDX118118A | TX | 1850~1910 | 1.5 | 60 | 1.5 | 100 | N, SMA | -30~+70 | 118×118×35 |
| RX | 1930~1990 | ||||||||
| UIYDX107107A | TX | 2500~2570 | 1.5 | 85 | 1.22 | 100 | N, SMA | -30~+70 | 107×107×30 |
| RX | 2620~2690 | ||||||||
| UIYDX9580A | TX | 5565~5725 | 1.5 | 70 | 1.45 | 50 | N, SMA | -30~+70 | 95×80×20 |
| RX | 5350~5510 | ||||||||
| UIYDX9580B | TX | 5725~5850 | 1.5 | 70 | 1.45 | 50 | N, SMA | -30~+70 | 95×80×20 |
| RX | 5565~5725 |
1-Packaging Details: Standard Export Carton Package.
2-Shipping Method: As below.
3-Delivery Time: 5-7 days after payment .
4-Payment: T/T, Paypal, Western Union
5-Others: Pls feel free to ask me, we will reply you soon.
Professional Radio Frequency (RF) / Microwave Device Supplier
Professionally customized Radio Frequency (RF) / Microwave Components Manufacture.
→Main product: 1) RF Isolators. 2)RF Circulators. 3)RF Filters. 4)RF Amplifiers. 5)Power Divider / Splitter.6) Duplexer/Triplexer. 7)Hybridge Combiner. 8)Coaxial Termination. 9)Coaxial Attenuator. 10)Directional Coupler. 11)Waveguide to Coaxial Adapter etc.
Advantage
we offer - ROHS Compliant
we offer - HFSS Simulation
we guarantee - One Year warranty
we guarantee - Fast Delivery
we support - OEM & Contract Manufacturing
