IG Dew Point Meter for Insulating Glass

Function: Measuring dew point meter of insulating glass

Related Standard:

ISO 20492 Glass in buildings — Insulating glass

GB / T 11944 Insulating glass

Techinical data:

Measuring range: -80°C ~ 100°C
Tube height: 300mm
Tube diameter: ø50mm
Accuracy: ≤1℃
Test environment: temperature: 23 °C ± 2 °C; relative humidity: 30% to 75% RH

1. Copper block; 2.Measuring tube; 3.Temperature probe; 4.Temperature sensor; 5.Digital display

Features:

1）Small size, easy to carry; probe and the refrigeration unit can be completely separated, easy to operate；

2）The digital thermometer has good stability and high measurement accuracy.

3）The measurement range can meet the heat resistance test requirements of laminated glass at the same time.

Attention:

1）The instrument is precise, handle lightly when in use, avoid knocking and falling;

2）Clean the measuring tube after use, keep the probe dry and clean, and keep it in the original package when not in use.

3）Close the switch in time after using the dew point meter, When not in use for a long time, the batteries of the digital display meter should be removed and placed.
