High Quality Stainless Tube Sheet for Heat Exchanger

High Quality Stainless Tube Sheet for Heat Exchanger

A tube sheet is a plate which is used to support the tubes in a shell-and-tube heat exchanger. The tubes are aligned in a parallel way, and supported and held in place by tube sheets. The tube sheet is a circular plate which is perforated so that the tubes can fit through the openings.

Product Specification :

1. Grade:Stainless steel,Carbon steel,Copper,Titanium

2. Size: OD≤2600 ,tube hole:8 to 32mm

3. Standard: ASME,TEMA,GB 150,GB151

4. Certification: ASME U-STAMP,TS

Material:

Common materials are: copper alloy, titanium, stainless steel, carbon steel

Different materials are used according to different use environments. Generally, Q345R container plates are used, such as one or two pressure vessels, no corrosive medium is circulated, and carbon steel composite plates can be used. In the environment of strong acid, high pressure, high temperature, nuclear energy, etc., stainless steel, 16 manganese, titanium alloy and other corrosion-resistant materials are needed, and the application of new synthetic materials has brought new vitality to tube sheet products.

Application :

Tube sheets are widely used in tube-tube heat exchangers, boilers, pressure vessels, steam turbines, large central air-conditioning and other industries.

It is mainly used in chemical containers, such as tube heat exchangers, pressure vessels, boilers, condensers, central air conditioners, evaporators, and seawater desalination. It plays a role of supporting fixed tubes. Rigid, and has great thermal conductivity.

Packages:

Package Type:rust-proof,wooden packed via fumigation

Wooden case or according to customers' requirement
