Product Feature of Electronic Potting Silicon (HY-9055) Electronic Potting Silicon (HY-9055) is a kind of low viscosity, Inherent flame resistance, two components addtion cured potting silicone
with heat-conducting. It cures with both on room temperature and heated temperature. It has the feature of the higher temperature the faster of the curing time. It can be applied to electronic
components for insulation, waterproofing, fixed and flame retardant. It mainly applied in electronic components surface with materials of PC(Poly-carbonate)PPABSPVC, etc. And metal materials.
Typical Application of Electronic Potting Silicon (HY-9055) Electronic Potting Silicon (HY-9055) could be applied to - high powered electronics, - DC/DC module and circuit board which requires heat
dissipation and high temperature resistance. -It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc.
TECHNICAL GUIDELINES of Electronic Potting Silicon (HY-9055) 1, Pls put part A and part B in separate container and stir evenly before mixing the two part together. 2, Mixing Ratio: Part A: Part B
= 1: 1 3, Deaeration the mixture in vacuum pump under 0.08 MPa for 3-5 minutes. Then the mixture could be used for pouring. 4, Pls note that the thickness of the silicone affects the curing time.
If the silicone used is a little thick, then the curing time will be a little longer. The temperature also affects the curing time. When in lower temperature, we suggest customers appropriately
heat the mixture to accelerate vulcanization. With temperature of 80~100, the silicone will cure in 15 minutes; While in 25 room temperature, the silicone will cure around 8 hours.
Features Part A Part BBefore Curing Appearence Gray Fluid White FluidViscosisty 2500± 500 2500± 500Operation features Mixing Ratio 1: 1Viscosisty(after mixing) 2000-3000Operating Time 120Curing
time 480Curing time 20
After Curing Hardness 55± 5Thermal conductivity ≥ 0.8Dielectric Strength ≥ 25Permittivity 3.0-3.3Volume Resisivity ≥ 1.0× 10 16Linear expansibility ≤ 2.2× 10 -4Fire Resistance 94-V1
