Beacon light for heliport new model

GS-HP/B Heliport beacon light, its base is caste by high intensity aviation aluminum with full sealed structure.

Light source adapts high efficient CREE chip and cooperate with condensing lens that owned independent research and developing patent, service life can up to 20yeras, offer high light intensity, long service life and other characteristics.

Lamp shade adopts PC, which has strong ability of corrosion, anti-UV, anti-shock.

Controlling circuit has strong ability of lighting protection and with anti-surge protection device, it can adapt to extremely bad working environment.

This light can emitted white color signal at night or dim day, indicate the location of helipad clearly

Name	Parameter
Model	GS-HP/B
Power voltage	Optional voltage: AC180V~264V
Power Supply Frequency	50HZ～60HZ
Power Consumption	≤20W
Working mode	Flashing 4times/2S
Optional Emitting Light Colors	White
Service Life of the Light Source	≥10years
Overall Size(mm)	255 x 255 x 210(mm)
Installation size	234mm x M8
IP Protection	IP67
Ambient Temperature	-55℃～85℃
Net Weight	3.8KG
Anti-Wind Ability	80m/s
