Electronic potting silicone rubber

The product is mainly used in electronic industry, the product into clear type and flame retardant. Ambient or heating sulfide. This product has vulcanization before melt viscosity bottom, facilitate infusion, vulcanization not exothermic, no low molecular emit shrinkage small, no corrosion, vulcanizates in - 60 °C --- -250 °C long-term use under, has moisture-proof, water resistant, weather resistant radiation-proof, aging etc. Temperature curing, suitable for mass potting, electric performance is superior.

Main application: used for electronic components potting, adhesive, coating materials, insulation, since moistureproof, shockproof, flame retardant functions.

Electronic potting silicone rubber for LED display module Product Feature

It is a kind of low viscosity, Inherent flame resistance, two components addtion cured potting silicone with heat-conducting. It cures with both on room temperature and heated temperature. It has the feature of the higher temperature the faster of the curing time. It can be applied to electronic components for insulation, waterproofing, fixed and flame retardant. It mainly applied in electronic components surface with materials of PC(Poly-carbonate),PP,ABS,PVC, etc. and metal materials.

Electronic potting silicone rubber for LED display module Typical Application

It could be applied to

- high powered electronics,

- DC/DC module and circuit board which requires heat dissipation and high temperature resistance.

-It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc.

Electronic potting silicone rubber for LED display module TECHNICAL GUIDELINES

1. Pls put part A and part B in separate container and stir evenly before mixing the two part together.

2. Mixing Ratio: part A: part B = 1:1

3. Deaeration the mixture in vacuum pump under 0.08 MPa for 3-5 minutes.Then the mixture could be used for pouring.

4. Pls note that the thickness of the silicone affects the curing time. If the silicone used is a little thick,then the curing time will be a little longer.The temperature also affects the curing time.When in lower temperature, we suggest customers appropriately heat the mixture to accelerate vulcanization. With temperature of 80~100°C, the silicone will cure in 15 minutes; while in 25°C room temperature, the silicone will cure around 8 hours.
