DC Fuse Holder
Product Quick Detail
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Standards: IEC 60269-1:2006 ; IEC 60269-2:2006 ; EN 60269-1:2007 ; HD 60269-2:2007
Approval: GOST (Type No.: AES10x38)
Insulation Voltage: 1000 VDC
Opration Voltage: 400-1000 VDC
Power: IEC, EN : 30 A, 1000 V DC ; UL, CSA : 30 A, 600 V
Power Dissipation: 0.3 W at nominal current. Suitable for fuse links to IEC 60269-2, -4, -6 (max. 3W)
Indication: Dual LED Indicators
Material: Temperature Stability 120°C, Self-extinguishing in acc. to UL 94, Creepage resistance CTI 200
Dimension: 18 MM x 81 MM x 58 MM (Single Pole)
