Solar DC Combiner Box
Product Quick Detail
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Brand: HENSEL (Germany) or Equivalent
Model: ENYMOD - Mi SERIES
Insulation Voltage: 1000VDC, Up to 630A (in accordance to IEC 60364-7-712)
Operating Temperature: -25 to 75 deg C
Material: Thermoplastic
Color: Grey RAL 7032E
Degree of Protection: IP65 & UV Resistant
Burning Behaviour: Glow Wire Test IEC 60695-2-11: 960deg C ; UL Subject 94: V-2 ; Flame Resistant Self-extinguish
Toxic Behaviour: Halogen Free & Silicone Free , in accordance to IEC 754-2
Dimension Available: Width x Height: 150x300; 300x300; 450x300; 600x300; 600x600 (MM); Depth: 170 or 214 (MM)
Model: ENYMOD - Mi SERIES
Insulation Voltage: 1000VDC, Up to 630A (in accordance to IEC 60364-7-712)
Operating Temperature: -25 to 75 deg C
Material: Thermoplastic
Color: Grey RAL 7032E
Degree of Protection: IP65 & UV Resistant
Burning Behaviour: Glow Wire Test IEC 60695-2-11: 960deg C ; UL Subject 94: V-2 ; Flame Resistant Self-extinguish
Toxic Behaviour: Halogen Free & Silicone Free , in accordance to IEC 754-2
Dimension Available: Width x Height: 150x300; 300x300; 450x300; 600x300; 600x600 (MM); Depth: 170 or 214 (MM)
