DC Power Surge Protective Device 03
Product Quick Detail
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Type: Type 2 (Protection in accordance to EN61643-11 ; Installation in accordance to EN61643-1)
Model: VD10 SERIES (Green Tag) / VC20 SERIES (Blue Tag) / VB40 SERIES (Red Tag)
Max Continuos Voltage, Uc: 1000VDC
Discharge Current, In / Imax: VD10: 10/20KA ; VC20: 20/40KA ; VB40: 40/80KA
Protection Level at 3KA, Up: < 1.1KV
Response Time, Ta: 25ns
Temperature, Tu: -40 to 80 Deg C
Enclosure: Material: PBT/PA-F UL94V-0 ; Mounting : 35mm Din Rail EN60715
Remote Contact Signal: 0.5A / 48V
