High Tensile Steel Wire Mesh

High Tensile Steel Wire Mesh is made of high tensile steel wire. Tecco mesh system is a kind of active rockfall barrier system, including tecco mesh, wire rope anchor, spike plate, boundary rope, sewing rope and steel clips. With the wire ropes and steel clips, the tecco mesh is fastened onto the mountain or slope surface tightly and firmly to block the large stones and reduce the damage of landslip or debris flow.

High Tensile Steel Wire Mesh Specification
Materia: High tensile steel wire.
Wire diameter: 3 mm, 4 mm.
Mesh type: Rhomboid hole.
Mesh size : 65 mm, 80mm inscribed circle diameter.
Tensile strength: Minimum 1770 MPa.
Braking load of single wire: 12.5 kN.
Mesh roll width: 1–3.5 m.
Mesh roll length:10–30 m.
Fitting : Steel anchor, claw type spike plate, soil or rock nails, clips, sewing rope, boundary rope. (The steel anchor is made of deformed steel bar of 25 mm diameter)
