High Precision Rotation Luminaire Goniospectroradiometer

LSG-1890BCCD/LSG-1800ACCD goniospectroradiometer is high precision automatic goniophotometric instrument for luminous intensity distribution measurement with facility for rotating the light source. The LSG-1890BCCD/LSG-1800ACCD can do the spatial CCT test and the intensity distribution test. It is for industrial laboratory photometric data measurement of luminaires such as LED luminaires, LED Plant Lighting, HID luminaires, fluorescent lamps and so on.

[caption id="attachment_6269" align="aligncenter" width="1920"]High Precision Rotation Luminaire Goniospectroradiometer[/caption]

Standard:
Full meet theEN13032-1

Measurement:
Luminous Intensity Data, Luminous Intensity Distribution, Zonal Luminous Flux, Luminaries Efficiency, Luminance Distribution, Coefficient Of Utilization, Luminance Limitation Curves Glare, Maximum Ratio of Distance to Height, Equal Illuminance Diagrams, Curves of Luminaires VS Lighting Area, Isocandela Diagrams, Efficient Luminescence Angle, EEI, UGR, CCT, CRI, Color Temperature Distribution, Spectrum, (x, y)/(u, v), PAR, PPF, PPFD 3D distribution test and etc.

Specification:
• LSG-1890BCCD/LSG-1800ACCD Goniospectroradiometer=LSG-1890B/LSG-1800A Goniophotometer System

LISUN Model	The Max Size for the Luminaires Under Test	Max Weight
Non-Flood Lamp Diameter*Depth	Flood Lamp (L*M)
LSG-1890BCCD	Φ 1900*550mm	600*600mm	60Kg
LSG-1800ACCD	Φ 1600*550mm	600*600mm	50Kg

Note: The LSG-1890BCCD is an update version for LSG-1800BCCD and LSG-1800XCCD. The LSG-1800ACCD is an update version for LSG-1700BCCD and LSG-1800CCD.
