P/N | ZXD-30 | ZXD-40 | ZXD-50 |
Hydrogen Production(m3/h) | 40 | 50 | 60 |
Oxygen Production(m3/h) | 15 | 20 | 25 |
Hydrogen Purity(V/V) | ≥99.99% | ≥99.99% | ≥99.99% |
Oxygen Purity(V/V) | ≥92.5% | ≥92.5% | ≥92.5% |
Operating load | 50%-100% | 50%-100% | 50%-100% |
Working Pressure(MPa) | 1.5~2.6 | 1.5~2.6 | 1.5~2.0 |
Hydrogen Moisture Content(g/m3) | ≤4 | ≤4 | ≤4 |
Hydrogen Alkalinity(mg/m3) | ≤1 | ≤1 | ≤1 |
Working Temperature(℃) | 85±5 | 85±5 | 85±5 |
Cooling water flow(m3/h) | 4.2 | 6.6 | 8 |
DC power consumption(kW·h/m3H2) | ≤4.3 | ≤4.3 | ≤4.3 |
External dimension of electrolyzer L×W×H (mm) | 2180x1160x1400 | 1660x1450x1580 | 2000x1450x1580 |
Electrolyzer Weight(kg) | 4800 | 6350 | 7100 |
Alkali concentration | 30% KOH | 30% KOH | 30% KOH |
Circulation quantity of alkali liquor(m3/h) | 2.0~2.5 | 2.75~3.3 | 3.0~3.7 |
Koh consumption (normal operation)(kg/unit) | 320 | 430 | 470 |
Green hydrogen is a promising key to accelerating the energy and environmental
transition towards carbon neutrality. We have the opportunity to act now in the
race against climate change by reaching industrial scale to make a difference.
Specialised in the design and assembly of electrolysers for producing green hydrogen.
We leverage our innovative spirit and cutting-edged technological know-how to serve
the industry and energy markets in China and around the world.
We move forward together with our customers, combining technological expertise and
personalised support. We focus on sharing, innovating, improving and taking initiative
together.
We drive change in energy use, as hydrogen offers a way to decarbonise all segments of
the economy and facilitate the integration of renewables in the energy system.
the hydrogen fuel cell
build a hydrogen fuel cell
hydrogen fuel energy
hydrogen as a fuel source
electrolyzer manufacturers
fuel cell generator for home
electricity to hydrogen
hydrogen power station
Technical characteristics: Using Palladium platinum bimetallic deoxidation catalyst, the deoxidation effect can reach oxygen content ≤ 1ppm, and the atmospheric deoxidation effect can reach oxygen content ≤ 5ppm. High quality molecular sieve is adopted, with high loading ...
Gas Purification Easy access to the glove box when using an external purification system Manual or PLC controlled 110V/50Hz or 220V/50Hz Working gas: Nitrogen, Argon, Helium Regeneration Gas: Working gas mixed with Hydrogen (5-10%) Available in multiple sizes ...
