Hand-held Veterinary animal ultrasound with convex probe PM-V0S

Application:

• Detection of pregnancy, estimation of litter size, disease diagnosis, fetal viability identification

Product Description:

• The application of microcomputer control and digital sweep surface converter (DSC), broadband low noise pressure control amplifier, digital logarithmic compression, digital dynamic filtering, frame correlation processing, edge enhancement and other technologies make the whole machine image more clear and high resolution. Portable pocket ultrasound, built-in battery, waterproof probe, easy to use. The operation is simple and accurate.​

​Technical parameters:

• 6.1 Scanning method: mechanical fan scavenging
• 6.2 Probe frequency: 3.5MHZ, support 2.5MHZ, 3.0MHZ, 3.5MHZ, 5.0MHZ four frequency conversion.
• 6.3 Display mode: B, B+B
• 6.4 Display depth: 46~208, adjustable
• 6.5 Gain adjustment: far field, near field and total gain adjustable
• 6.6 Frame frequency: 30 frames per second
• 6.7 Image gray scale: 256
• 6.8 Image multiplying: 15 kinds of magnification
• 6.9 Screen size: 5.6inch LCD screen​

Host power consumption:

• Non charging working condition 13W/ charging work 25W

Host size: 240X120X45 (mm)

Host weight: 900g

Standard configuration:

• Main engine (including a lithium ion battery), 3.5MHz waterproof mechanical fan scanning probe, instruction manual, power adapter.​

Probe adapted

• 3.5.0MHz waterproof mechanical fan scanning probe

Scope of application:

• Large scale pig farms, artificial insemination stations, feed / veterinary drug distributors and enterprises, scientific research teaching units
