12" x 2" Mobile Home Trailer Electric Brake Assembly

Features

lThe 12” Electric Brake Assemblies are specialized for Mobile Home Axles.

lDexter Axle Co., develop mobile home axles in order to reduce the cost of suspension system.

lThis system was not approved by DOT, but approved by HUD (Housing and Urban Development).

lAssembly comes complete with magnet, arm, and weld on backing plate.

lMobile home electric brake assembly is welded onto the beam and not intended to be field replaced.

Specifications

ØDimension: 12 inch x 2 inch

ØAxle Capability: 4500 lbs to 6000 lbs Axle

ØInstallation Method: Weld On

ØBrake Fit: Left Hand / Driver Side / LH, Right Hand / Passenger Side / RH

Product Composition

²12” x 2" Electric Brake Shoe Set x 1

²Weld On Back Plate x 1

²Round Magnet with Spring x 1

²Magnet Arm x 1

²Brake Adjuster x 1

²Long Spring x 2

²Short spring x 1
