(1)Main parameter | |
Tensile force | 30 T |
Jaw center distance Max | 3500 mm |
Jaw center distance Min | 1100 mm |
Jaw rotation | ±180° |
Center distance of rotating shaft | 1100mm |
(2)Stretching cylinder | |
Vertical distance of drawing cylinder on die table | 200-900 mm |
Stretching cylinder stroke | 700 mm |
Horizontal swing | ±30° |
(3)bending arm | |
Movement range (per bending arm) | forward10°,backward90° |
Move rate | 1 º/S~3 º/S |
bending arm stroke | 1000mm |
(4)Lifting cylinder | |
Lifting stroke | 700mm |
Move rate | 1-10 mm/s |
(5)workbench | |
Height from ground | 1000 mm |
size |
1500*1000*65mm |
