Model:BP72160\BP72205\BP72277
Electrical Specification
Nominal Voltage:76.8V
Nominal Capacity:160Ah\205Ah\277Ah
Energy:12.28kWh\15.51kWh\21.27kWh
Resistance:≤50mΩ
Efficiency:≥98%
Self Discharge:<3% per month
Cycle life:>3000 cycles @80% DOD
Charge specification
Standard charge:
BP72160:Constant current 40A. Constant voltage 87.6V, to charge current 8A cut-off @25±2℃\BP72205:Constant current 51A. Constant voltage 87.6V, to charge current 10A cut-off @25±2℃\BP72277:Constant current 70A. Constant voltage 87.6V, to charge current 13A cut-off @25±2℃.
Standard charge time:Approx. 5h
Max. Charge current:160A\205A\277A
Charge Voltage cut-off:87.6V (1±0.2S)\87.6V (1±0.2S)\87.6V (1±0.2S)
Charge temperature: 0~45℃
Discharge specification
Max. Constant discharge:160A\205Ah\277Ah
Peak discharge current:320A (10S)\410A (10S)\500A (10S)
Discharge voltage cut-off:55V
BMS discharge cut-off:55V
Short circuit protection:200-600μs
Discharge temperature: -20~60℃
Mechanical Specifications
Dimensions(L*W*H):1000*420*240mm\1000*420*240mm\1000*420*240mm
Weight:98kg\118kg\156kg
Terminal Type:CAN connector
Case Material:Metal
Enclosure protection:IP65
Combination method:24S1PTotal cells:24 pieces
