Optical JGS1 Meniscus Bi Convex Lens Stock

Place Of Origin
Changchun
Minimum Order
1
Packaging
10PCS
Delivery
15 Days

Spherical Positive Mensicus Lens

H-K9L Positive Meniscus Lens has excellent transmittance from visible to near infrared (350-2000nm).H-K9L (N-BK7) is a commonly used optical glass for the preparation of high-quality optical elements. When the additional advantages of UV melting quartz (good transmittance and low thermal expansion coefficient in the UV band) are not needed, H-K9L is generally selected.Positive meniscus lenses are designed to minimize spherical aberration and can be used alone to obtain a minimum converging spot, or when combined with another lens to reduce the focal length and thus increase the numerical aperture.For converging parallel light, the convex surface of the lens should face the source to minimize spherical aberration.


Spherical Negative Mensicus Lens

The H-K9L Negative Meniscus lens has excellent transmittance from visible to near infrared (350-2000nm).H-k9l (N-BK7) is a commonly used optical glass for the preparation of high-quality optical elements. When the additional advantages of UV melting quartz (good transmittance and low thermal expansion coefficient in the UV band) are not needed, H-K9L is generally selected.The central part of a negative menuscule lens is thinner than its edge, causing light to diverge and designed to minimize spherical aberration.They are often used in conjunction with other lenses to increase the focal length and thus reduce the numerical aperture (NA) of the optical system.When used for astigmatism, the concave surface should be oriented towards the beam to minimize spherical aberration


Specifications

Structure: Mensicus Lens

Material: Optical Glass,BK7,H-K9L,UVFS,Germanium,Silicon,CaF2,MgF2,ZnSe,ZnS,Sapphire.

Dia.0.35-700mm

Dia.Tol.+0.00/-0.01mm

Surface Quality:10-5

Surface Irregulatiry:λ/10 @632.8nm or customer design

Thickness tolerance:+0/-0.02mm

Clear Aperture>90% of diameter

Chamfer:0.05-0.5mm

Centeration<30 arcsec

Coating:Single Mag2, Multiple Layers AR Coating

A: 350-650nm
B: 650-1050nm
C: 1050-1585nm
D: Customer Design
