Armouring Cable Wire
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Galvanized Steel Wire for Cable Armouring
Firstlin supplies big package cable armouring galvanized wire normally hot dipped with thick zinc coating.
Technical Information of Hot dipped galvanized steel wire
Tensile strength: 340-500 N/mm2 for all sizes
Elongation: Min. 10% for all sizes
Coil weight: 300-800kgs/coil
Packing: junbo coil, plastic bag
Wire dia(mm):0.90, 1.25, 1.60, 2.0, 2.5, 3.0, 3.9
Tolerance(mm):+/-0.025, +/-0.035, +/-0.045, +/-0.050, +/-0.065, +/-0.07, +/-0.075
Max Elec. resistance(ohm/km): 216.92, 122.02, 68.64, 43.93, 28.11, 19.52, 11.55
Min Zinc coating(g/m2): 150, 200, 230, 240, 260, 275, 290
Coil dia.(ID/OD mm): 0.9mm-1.6mm: 340/590, 370/590, 450/800, 430/760; 2.0mm-3.9mm: 450-800, 508-840.
 |  |
| Hot Dipped Armoring Cable Wire | Galvanised Steel wire for Cable Uses, with Handles |
Specification of Armouring Wire for Cables:
| Material: | Sizes: | Tolerance (mm): | Tensile strength: | Elongation (Min): | Zinc coating g/m2: | Elec. Resistance (Max.ohm/km) : | Coil ID (mm): | Coil Wt.(kgs): |
| Galvanized steel wire for cable armoring | 0.87mm | +/-0.025 | 340-500 N/mm2 | Min.12% | Min.150 | Max.233 | 350-500mm | 400-500 |
| 1.21mm | +/-0.035 | 340-500 N/mm2 | 12% | 180 | 120 | 350-500mm | 400-500 | |
| 1.54mm | +/-0.045 | 340-500 N/mm2 | 12% | 195 | 74.13 | 350-500mm | 500-600 | |
| 1.94mm | +/-0.05 | 340-500 N/mm2 | 12% | 215 | 46.71 | 350-500mm | 500-600 | |
| 2.43mm | +/-0.065 | 340-500 N/mm2 | 12% | 230 | 29.77 | 350-500mm | 500-600 | |
| 3.05mm | +/-0.07 | 340-500 N/mm2 | 12% | 255 | 18.90 | 350-500mm | 500-600 | |
| 3.80mm | +/-0.075 | 340-500 N/mm2 | 12% | 275 | 12.18 | 350-500mm | 500-600 |
- Country: China (Mainland)
- Business Type: Manufacturer
- Market:Africa,Americas,Asia,Emerging Markets,Europe,European Union,G20,Middle East,Oceania
- Founded Year:1998
- Address:No.68 ,Renxing Road, Dezhou, China.
- Contact:Li Zhixin
