240W 12V 16A Battery Charger

240W 12V 16A Battery Charger

Typical output: 12V 16A battery charger

Fully auto 4 stages charging process by MCU controller

4 LED indicate the battery capacity from 25%~100%

Worldwide AC input 100V-240V

Charging stage: Small current pr-charge; constant current charging; Constant voltage charging

The Specifications Of 240W 12V 16A Battery Charger

Charger Model AC Input Voltage Battery Voltage Max Voltage(V) Max Current (A)

AP-PN240CH01460160 100-240 12 14.6 16

AP-PN240CH02920080 100-240 24 29.2 8

AP-PN240CH04200060 100-240 36 42 6

AP-PN240CH05460040 100-240 48 54.6 4

AP-PN240CH01200160 100-240 12 14.7 16

AP-PN240CH02400080 100-240 24 29.4 8

AP-PN240CH03600060 100-240 36 44.1 6

AP-PN240CH04800040 100-240 48 58.8 4

INPUT AC Input Voltage Range 100V ~ 240V

AC Input Frequency 45~65HZ

AC Power Factor Correction ≥0.98

OUTPUT Output Voltage Range 12~60V

Output Power Range 16A（Max）

VIBRATION 10～50HZ 2G 10 minutes，X，Y，Z /60 minutes

DIMENSIONS(mm) (L)203х(W)81х(H)47.5

Protections Over current protection ,Over Voltage Protection ,Short- circuit Protection Reverse Connection Protection ,Battery open-circuit protection

CERTIFICATIONS CE ROHS

PACKING DETAILS 1.2kg/pcs

1pcs/Carton

Carton size: 203*81*47.5mm

Shen Zhen Shi Alrightpower Technology Co., Ltd is a professional 12v 20a battery charger supplier, we provide 180w power adapter, Power Adapter, industrial power adapter and etc. For more information, please feel free to contact us!
