Micro Wireless Backshell Connector for Choice

Description of Micro Wireless Backshell Connector

This type of device is designed to provide screening, sealing, and reparability. Micro d connector backshell connect cable shields to Micro-D connectors, providing strain relief and mechanical protection. Engineered to help resist corrosion and fit a wide range of circular connectors, backshell and adapter components help protect connections from mechanical wear, environmental conditions, and electromagnetic interference (EMI). These backshells are made out of aluminum alloy. Electroless nickel is the most widely used finish. These backshells are compatible with industry- standard metal shell M83513 type connectors. These m83513 04 backshell, m83513 03 backshells are available with and without screen termination, providing long-term, high performance in sealed and unsealed electronics systems.

Removable jackscrews according to MIL-DTL-83513/05

For pigtail crimping & solder cup connectors only.

2 sizes of hardware: one version for shell sizes from 9 to 69 ways and another version for the 100-way shell size.

1 kit consists of 2 screws and 2 e-rings.

Hex socket head or slot head.

Material: passivated 300 series stainless steel

Contact arrangements of Micro Wireless Backshell Connector

Metal shell: 9, 15, 21,25,31,37,51,66,74, 100 contacts

Plastic shell: 9, 15, 21,25,31,37, 51 contacts

MICRO-D EMI BACKSHELL of Micro-D Connector Backshell

- Micro-D aluminum backshell for EMI termination.

- Supplied with stainless steel hardware.

- Various entry sizes & shapes.

- Available for standard and micro termination.

- Shell size from 9 to 100.

Contacts *Twist pin contacts, high density interconnection, Beryllium copper (BeCu), gold over nickel plating

The thickness of Gold plating * ≥1.27micron

TWIST PIN * Male contact, fitted to plug connector.

Socket * Female contact, fitted to socket connector (also known as socket).

Insulator* 20% GFPPS (20% glass filled polyphenylene sulfide)

Insert * Moulded insulation housing, separating each connection.

Interfacial Seal * Fitted to socket connector only

Shell *Connector metal body plated nickel or cadmium.

Jackscrew *High or low profile, hexagonal socket or slotted head.

Jackpot* Mates with jackscrew.

LCP * Liquid Crystal Polymer.

Potting * Epoxy compound used as an encapsulant.

Introduction of Micro Wireless Military Connector Backshells

Series * Mil Micro D Connector

Terminal Mounting * Crimping wireless connector

Standard connector * Manufactured to the standard dimensions and specifications.

Special connector * A standard connector modified to meet specific requirements.

Custom-made connector * Designed to meet specific customer requirements.

Pigtail connector * Connector with insulated or uninsulated wires.

Harness * Multi-branched cable assembly.

Sunkye TwistPin equipped MIL-DTL-83513 Micro-D subminiature connectors features outstanding mating performance, durability, and minimal contact resistance.
