Heavy Duty Tube Laser Cutting Machine Manufacturer

Overview of Heavy Duty Tube Laser Cutting Machine

Large tube laser cutting uses a focused high-power-density laser beam to irradiate the workpiece, so that the irradiated material quickly melts, vaporizes, ablates, or reaches the ignition point while blowing away the molten material. And with the help of a high-speed airflow coaxial to the beam, thus realizing the cutting of the workpiece. Laser cutting is one of the thermal cutting methods.

We have launched the heavy-duty tube laser cutting machine, a large cutting machine, for processing super-long and super-heavy pipes. From automatic feeding to stable clamping, and finally, to automatically receive the finished workpiece, the whole process can be fully automated. Save time and labor for you.

Professional Heavy Chucks

Compared with the general pipe laser cutting machine, the load-bearing weight of the chuck of a large china cnc tube laser is increased to 500kg. The maximum load-bearing capacity of a single tube can reach 1.8 tons. The most extended length supports automatic loading and cutting of 12 meters of pipes.

Friendly Operation

The equipped chain-type automatic loading and unloading system can support up to 12 meters of heavy-duty pipe loading and unloading. The number of single preparations can reach 6 to ensure the continuity of the processing process and reduce equipment downtime. Only one person can efficiently complete the entire process.

Supports Multiple Types Of Pipes

Large cutting machine fully supports the cutting of round pipes, square pipes, rectangular pipes, elliptical pipes, channel steel, angle iron, I-beams, slats, profiles, special-shaped pipes, etc., and supports bevel processing.

CE Standard

The large cutting machine strictly adheres to the CE standard. The overall safety protection reaches the highest level without worrying about safety.

Video Display of Heavy Duty Tube Laser Cutting Machine P35120

Golden Laser different types of metal pipe cutting show

Application of Heavy Duty Tube Laser Cutting Machine

Construction machinery industry:

Many major load-bearing structures in construction machinery use ultra-long and ultra-thick channel steel, I-beams and other pipes. The traditional plasma cutting and flame cutting methods have low processing efficiency and quality. But the large cutting machine can completely solve the problem of heavy pipe processing. In the future, cnc profile cutting will gradually replace these methods. The material texture and style are maximized, and the building's proportions, texture, and space are rigorously expressed. With the delicate mind of laser process, all the structural elements are fully expressed in the sectional plane.

Shipbuilding industry:

The automatic processing capability of the large cutting machine can speed up the processing efficiency of the pipe components. Nowadays, "precision shipbuilding" and "fast shipbuilding" have become the main trends in the development of ship manufacturing, and cnc pipe cutting machine technology has been developing rapidly, accounting for more than 70% of the entire laser processing industry. The marine manufacturing industry is mainly based on the raw material of steel plates. Using the laser to cut the plate can greatly shorten the production cycle and reduce the processing cost at the same time. The use of a laser cutting machine for undercutting cancels the assembly margin, eliminates the phenomenon of on-site trimming, reduces labor and plate waste, significantly accelerates the speed of frame assembly, and improves the quality of assembly significantly.

Steel structure industry:

Large laser cutter can realize welding-free, making the product more stable. Tube cutting is currently the largest share of laser applications of cnc pipe cutting machine china, most of which are laser cutting applications for medium and high power metal materials. This, of course, includes stainless steel, carbon steel, copper, aluminum and other major metals in everyday life, of which stainless steel, carbon steel accounted for the most.

Technical Data of Heavy Duty Tube Laser Cutting Machine

Model name P35120

Workpiece length 0-12000mm

Tube diameter range 20-350mm

Type of tube Round tube, square tube, rectangular tube, oval tube, channel steel, I-beam, etc.

Single tube bearing weight 30kg/m

Laser source IPG/nLIGHT/Raycus

Laser power 1500W-6000W

Positioning accuracy ±0.03mm

Rotational speed 70r/min

Support bevel cutting Yes

Automatic deslag function Option

Weld recognition Option

Auto feeder Standard chain loading and unloading system

Loading size 6* 12000mm

Auto feeder maximum weight 2.5T

Capacities

Material 1500W 2000W 2500W 3000W 4000W 6000W

Carbon steel 10 12 14 16 20 25

Stainless steel 6 8 10 10 12 16

Galvanized steel 5 6 8 8 10 12

Aluminum 4 5 6 6 10 16

Brass 3 4 5 5 8 10

Copper 2 2 3 3 4 6

Highlights of Heavy Duty Tube Laser Cutting Machine

Chain Drive Loading and Unloading System

The loading and unloading adopt a chain drive model without manual intervention. Chain drive, choose the chain type and length and tensioning method according to the primary factors such as load, speed, and working environment. The large laser cutter can ensure an accurate transmission ratio, transferring more power and acting on the shaft with less force and high transmission efficiency.

Intelligent Heavy-duty Chuck With Large Clamping Range

Large laser cutter adopts 3 heavy-duty pneumatic chucks with a maximum load of 500kg and a 20-350 mm clamping range. The clamping pressure of the pneumatic chuck supports digital visual adjustment, which is precise and easy to control.

Servo Reducing Wheel Support System

Both the loading end and the unloading end are equipped with servo reduction wheel brackets to increase the load-bearing capacity. When cutting different types of pipes, input the pipe diameter data through the cnc laser pipe cutting system to automatically adjust the wheel support angle. Servo motor control, positioning is more accurate.

No manual adjustment is required, and the operation is more straightforward and safer.

Modular Mechanical Structure Of Side Rail

The large laser cutter adopts the side rail design and chuck suspension type, accommodating larger pipes. The large cutting machine structure adopts the modular design, realizing segmental splicing installation and convenient installation and disassembly. Even if the length of the whole machine exceeds 24 meters, there are no restrictions on transportation.
