VE Vertically-Mounted Slewing Drive

VE Vertically-Mounted Slewing Drive

The VE Series dual axis slew is a vertical mounted design for low-speed (<1 RPM) outdoor applications. Its special structure effectively simplifies the complex structure design of the EPC bracket and reduces the whole system cost.This product has a flexible input interface form, which is convenient for connecting various hydraulic motors and geared motors.

Slewing Drive Performance Data

Normal Output Torque 2500N.m

Max. Output Torque(3sec.) 6000N.m

Backwards Holding Torque 20000N.m

Tilting Torque 13500N.m

Static Radial Rating 110KN

Static Axial Rating 60KN

Dynamic Radial Rating 60KN

Dynamic Axial Rating 30KN

Slewing Drive Ratio 63:01:00

Rotating Output Rated Speed 0.032rpm

Efficiency 40%

International Protection(IP) 65

Tracing Precision 0.1°

Worm Drive Temperature -20℃-+80℃

Self-Lock Drive Yes
