Welded Reinforcing Mesh Fabric

GI. Welded Wire Reinforcement Mesh is the irreplaceable concrete reinforcing mesh used in modern construction. It is made of high tensile steel wire spot welded into a square or rectangular mesh mat structure, prefabricated for concrete elements uses. Both electro galv. and hot dipped galvanised treatment available for anti corrosion resistance and long term uses.

Wire / Bar Diameter: 4mm-16mm

Space center of neighbor steel bar
Vertical: 100mm, 150mm, 200mm, 300mm
Horizontal: 100-400mm
Width: 0.5m-3m
Lengt: 2m-6m

Welded steel bar panels are widely used in construction reinforcement, the ground for the tunnels, bridges, highway, airport and wharf, also in construction of wall body.

Features and Benefits
• Economic transport;
• Ease and economy of storage space;
• Reduction of implementation time (high application performance);
• Installation does not require skilled labor;
• Quality ensured by the implementation in factory;
• Reduction of waste and failings.

Structures:

Concrete Reinforcement Welded Mesh Sheet consists of pieces of wire or rebar welded together to form a grid pattern.

The size of the grid pattern is typically 4-inch-by-4-inch up to 8-inch-by-8-inch.

The hole of the grid is in square or rectangular shape:

Rectangular Welded Mesh with wires crossed in a form of a rectangle, and longitudinal wire as the supporting ones

Square opening welded steel mesh with wires crossed in a form of a square, and both longitudinal and transversal wires as supporting ones
