600W 24V 20A Battery Charger
Product Quick Detail
- FOB Price
- USD $1.20 / Piece
- Place Of Origin
- Shenzhen,China
- Minimum Order
- 1000
- Packaging
- PE bag + outer Carton
- Delivery
- 35days to 40days
Specifications
Typical output: 24v 20a battery charger
Fully auto 4 stages charging process by MCU controller
4 LED indicate the battery capacity from 25%~100%
Worldwide AC input 100V-240V
Charging stage: Small current pr-charge; constant current charging; Constant voltage charging
The Specifications Of 600W 24v 20 amp battery charger
Charger Model AC Input Voltage Battery Voltage Max Voltage(V) Max Current (A)
AP-H/LF600CH01460250 110/220 12 14.6 25
AP-H/LF600CH02920200 110/220 24 29.2 20
AP-H/LF600CH04200150 110/220 36 42 15
AP-H/LF600CH05460120 110/220 48 54.6 12
AP-H/LF600CH07140100 110/220 60 71.4 10
AP-H/LF600CH08400080 110/220 72 84 8
AP-H/LF600CH01200250 110/220 12 14.7 25
AP-H/LF600CH02400200 110/220 24 29.4 20
AP-H/LF600CH03600150 110/220 36 44.1 15
AP-H/LF600CH04800120 110/220 48 58.8 12
AP-H/LF600CH06000100 110/220 60 73.5 10
AP-H/LF600CH07200080 110/220 72 88.2 8
INPUT AC Input Voltage Range 100V ~ 240V
AC Input Frequency 45~65HZ
AC Power Factor Correction ≥0.98
OUTPUT Output Voltage Range 12~60V
Output Power Range 15A（Max）
VIBRATION 10～50HZ 2G 10 minutes，X，Y，Z /60 minutes
DIMENSIONS(mm) (L)183х(W)122.5х(H)69
Protections Over current protection ,Over Voltage Protection ,Short- circuit Protection Reverse Connection Protection ,Battery open-circuit protection
CERTIFICATIONS CE ROHS
PACKING DETAILS 1.8kg/pcs
12pcs/Carton
Carton size: 535*315*280mm
Shen Zhen Shi Alrightpower Technology Co., Ltd is a professional 12v 20a battery charger supplier, we provide 180w power adapter, industrial power adapter and etc. Want to know more, contact us.
- Country: China (Mainland)
- Business Type: Manufacturer
- Market:Africa,Americas,Asia
- Founded Year:2019
- Address:The 8th Building,Hongye Industrial Zone,Jiuwei Village,Xixiang,Bao'an District,Shenzhen,China
- Contact:alrightpower .com
