PATTERNED SAPPHIRE SUBSTRATES

Minimum Order
1
Packaging
N/A
Delivery
15 Days
Sapphire wafer is the most widely used substrate material in semiconductor lighting industry, and patterned sapphire substrate (pss wafer) is the general method to improve the luminous efficiency of semiconductor lighting devices. These pattern sapphire substrate are with periodic structures of various shapes such as cone, dome, pyramid, and pillar, etc.

CRYSCORE OPTOELECTRONIC LIMITED has been a professional manufacturer specialized in high-quality sapphire wafers and optical windows since 2008. We provide optical sapphire, sapphire rod, sapphire ingot, Sapphire substrate and etc. Want to know more? Please contact us.
