What is dome switch pcb

Metal shrapnel (also known as pot or piece, metal dome, snap dome), made of ultra-thin (0.05mm-0.1mm thickness) and ultra-thick (usually high hardness) stainless steel 301 or 304 material. Metal dome is an important part of the snap dome switch PCB.

They are momentary switch contacts that become normally-open tactile metal dome switch when used in conjunction with a printed circuit board (PCB).

PCB is also known as printed circuit boards because it is made by electronic printing. A printed circuit board is a substrate for assembling electronic components and is a printed board on which a point-to-point connection and a printed component are formed on a general-purpose substrate in a predetermined metal core printed circuit board design.

Metal domes can be divided into several groups: round metal dome, triangle metal dome, rectangular metal dome, four-leg metal dome(cross shape), square shape metal dome and other special shapes. PCB membrane switches are widely applicable. It can be applied in areas including mobile phones, diagnostic equipment, industrial controls, test equipment, and measurement equipment, etc.

Advantages of Our PCB with Metal Dome

Making smaller and thinner packages possible

Dome switch PCB with high product reliability

Low-profile and lightweight design

PCB membrane switch with consistent tactile response

Actuation forces are available to meet any needs of applications

Metal dome membrane switch which is able to be used even in the rough environment
