KNITTED MESH SPRING FOR PISTON SEALS

We supply quality stainless steel knit mesh springs for piston seals.

Knit Mesh Spring

Material: Stainless spring steel
9.5mm O.D., 0.19mm Diameter Stainless Steel Spring Wire

Structure
12 Loops around the perimeter
Loop To Loop Distance (pitch): 5.5mm

Knit Mesh Spring Stiffness
Knitted mesh for piston seal has a specific stiffness requirement:
1- 1.2 N Per 1cm of length when compressed from 9.5mm to 7mm between two plates

Other properties: Mesh Spring must bend down to 18mm radius or less

Uses: To form closed loop, cut 72cm piece of mesh spring, insert one end into the other (5cm deep)

Supply Condition:
Remove all burrs and sharp edges.
The seal springs are packaged in a manner to prevent damage during shipment.
