XH-28-D1X2-U Optical Switch Equipment
Product Quick Detail
- Minimum Order
- 1
- Place Of Origin
- china
- Packaging
- Carton packing
- Delivery
- 15 Days
Specifications
XH-28-D1X2-U optical switch equipment
Features
(1) It has the characteristics of low insertion loss and fast switching speed.
(2)It can be controlled by RJ45 Ethernet or RS-232 serial port command.
(3)28 independent control optical switch buttons, easy to operate.
(4)Two different colors of LED display lights, showing the status of the light path.
(5) Equipment power supply supports AC: 85~265V AC power supply.
Performance
| Name | Parameter |
| Model | XH-28-D1X2-U |
| Working wavelength | 850/1310nm |
| Test wavelength | 850nm |
| Insertion loss | ≤ 1.5 dB |
| Repeatability | ≤ ±0.02 dB |
| Return loss | ≥ 35 dB |
| Crosstalk | ≥ 50 dB |
| Wavelength dependent loss | ≤ 0.25 dB |
| Polarization dependent loss | ≤ 0.05 dB |
| Switching time | ≤10 ms(Adjacent channel) |
| Fiber type | MM(50/125um) |
| Connector form | LC\PC(customizable) |
| Monitoring port | RJ45,RS-232 |
| Working power | AC:85~265V |
| Operating temperature | -5 ~ +55ºC |
| Storage temperature | -40 ºC ~ +85 ºC |
| Chassis size | 270mm X 190mm X 135mm |
