The Processing of Teflon Bellows

Minimum Order: 1

Packaging: N/A

Delivery: 15 Days

Bellows is a corrugated tube shaped elastic part which can be used in the component of the mechanical seal compensation ring, which can be expanded under the external force or self elastic force and compensates the auxiliary seal of the ring. The bellows type agitator mechanical seal design has no relative sliding on the shaft, no abrasion on the shaft, and good follow-up, and is widely applied to the pump products, like water pump seals . HTB series anti-corrosion engineering plastic pumps are widely used in petrochemical, mining, chemical and pharmaceutical industries, and are used to transport toxic and harmful chemical media including acid, alkali, pulp and sewage. Therefore, it has special requirements for its anti-corrosion, high wear resistance and anti-leakage. The mechanical seal of this series of pumps is made of polytetrafluoroethylene bellows. Teflon bellows require high precision, low elastic modulus of material, easy deformation of corrugated structure and difficult turning. In view of the material and structural characteristics of bellows, a practical and reliable technology and manufacturing method for corrugated pipe turning is put forward.

Corrugated pipe is made of three sections of solid Teflon, Teflon filled with glass fiber and Teflon filled with carbon fiber. Bellows have different properties and uses for different materials: 1) Teflon containing carbon fiber has the properties of high tensile strength, corrosion resistance and wear resistance; 2) Pure PTFE has a density of 2.29 g/cm' and a water absorption rate of less than 0.01%. It has the characteristics of corrosion resistance, aging resistance, high temperature resistance, good mechanical toughness and elasticity, so that the seal has compression and resilience and permanent deformation is small; 3) The Teflon containing glass fiber is resistant to aging and corrosion, and the dimensional stability is good, so that the sealing parts can achieve ideal matching status in assembly.

With years' experience, Hangzhou Sealcon Fluid Machinery Co., Ltd has provided numerous solutions for different industries. Adopting advanced sealing technology, Sealcon's mechanical seals are sold worldwide and receive good comments.

Country: China (Mainland)
Business Type:
Market:
Founded Year:2011.5
Address:A1-3-603 xixi center, wenyi west road, xihu district, Hangzhou
Contact:michael yu
