Thermally Conductive Silicone Rubber

GA-96*0 series thermal conductivity silicone rubber have good thermal conductive property, excellent heat transfer performance.

Silicone rubber thermal properties

GA-96*0 Series Heat Cure Rubber

Feature: good thermal conductive property, good processability among thermally conductive rubbers

Heat Conductive Silicone Rubber Application: thermal conductive gasket, rubber strip, thermal conductive sheath, thermal conductive silicon cloth

Typical Characteristics

Product code GA-9630 GA-9640 GA-9650 GA-9660 GA-9670 GA-9680 GA-9680B

Appearance white black

William plasticity 160 180 200 220 240 270 270

Hardness(ShoreA) 30 40 50 60 70 76 79

Density(g/cm³) 2.1 2.13 2.15 2.2 2.25 2.04 2.35

Tensile strength(Mpa) 1.0 1.5 2.0 2.0 2.5 4.5 4.7

Elongation(%) 800 750 700 600 500 80 130

Tear strength(KN/m) 6 6 6 10 10 8.0 11.3

Coefficient of thermal 0.8 0.8 0.8 0.9 0.9 0.8 0.9

As one of the most professional silicone rubber manufacturers in china, we provide moulding silicone, coating silicone, oil silicone and etc. For more information about thermal conductivity of silicon rubber, please feel free to contact us!
