12x10ST-AH 渣浆泵 是最先进的渣浆泵,具有油或油脂润滑轴承组件,可与其他主要品牌完全互换。12x10 离心渣浆泵可采用专为重型渣浆应用设计的高铬合金材料。
设计特点:
√ 12x10ST-AH渣浆泵过流部件采用耐磨高铬合金。
√ 12x10ST-AH泵轴承总成采用圆柱形结构,叶轮与前衬板的间隙调整方便,维修时可完全拆卸。轴承装配使用油脂润滑。
√ 所有渣浆泵的轴封均可采用填料密封、副叶轮密封和机械密封。
√ 放电支路可按要求45度角定位,任意8个方向定位,以适应其工作现场的安装使用。
√ 驱动方式有V带驱动、齿轮减速机驱动、液力偶合器驱动、变频驱动装置等。
√ 性能宽,汽蚀余量好,效率高。渣浆泵可多级串联安装,满足远距离输送。
东兵卫® 12/10 ST AH渣浆泵性能参数:
模型 |
最大限度。力量
(千瓦) |
材料 | 清水性能 |
叶轮
叶片号 |
|||||
衬垫 | 叶轮 |
容量Q
(立方米/小时) |
头高
(米) |
速度n
(每分钟转数) |
有效。η
(%) |
汽蚀余量
(米) |
|||
12/10ST-AH | 560 | 米 | 米 | 936~1980 | 7~68岁 | 300~800 | 82 | 6个 | 5个 |
Tobee®12/10 ST AH 渣浆泵应用:
12/10 ST AH 泥浆泵广泛用于许多行业中输送腐蚀性/磨蚀性和高浓度泥浆。如金、银、铁矿石、锡、钢、煤、钛、铜、矿砂、铅和锌。其他各种行业包括钼、电力公用事业、油页岩、水和污水处理公用事业、建筑领域、沙子和砾石、烟草和农业(猪、家禽、奶牛粪便)、采矿和矿物、研磨和筛分、水力旋流器分离、磁选、浮选、浓缩、过滤、浸出、溶剂萃取和电积、球团、尾矿、冶金、焙烧、退火和酸洗、焦炭淬火、热轧轧钢、中和、泥浆处理和废物处理。
