Tobee® abrasive slurry pump with motor
Product Quick Detail
- FOB Price
- USD $4,900.00 / Piece
- Place Of Origin
- 中国
- Capacity
- 162-360m3/h
- Speed
- 800-1550rpm
- Eff.
- 65%
- Handling Solids
- 44mm
- Minimum Order
- 1
- Size
- 6" x 4"
- Head
- 12-56m
- NPSHr
- 5-8m
- Power
- Max.60kw
- Packaging
- Wooden
- Delivery
- 30 Days
Specifications
6x4D-AH Slurry Pump is a single-stage, single-suction and horizontal heavy duty centrifugal slurry pump with a cantilever design, The 6x4 slury pumps are mainly used in solids containing applications. Depending on process conditions, equipment should be suitable for highly abrasive or corrosive liquids.
Design Features:
√ Cylindrical structure of bearing assembly: convenient to adjust the space between impeller and front liner and can be removed completely.
√ Interchangeable anti-abrasive wet parts made of high-chrome alloys.
√ The discharge branch can be oriented to any eight positions at the interval of 45 degrees.
√ Various drive types: DC (direct connection), V-belt drive, gear box reducer, hydraulic couplings, VFD, SCR control etc.
√ The shaft seal uses the packing seal, expeller seal and mechanical seal.
Tobee® 6/4 D AH Series Slurry Pumps Performance Parameters:
| Model |
Max. Power
(kw) |
Materials | Clear Water Performance |
Impeller
Vane No. |
|||||
| Liner | Impeller |
Capacity Q
(m3/h) |
Head H
(m) |
Speed n
(rpm) |
Eff. η
(%) |
NPSH
(m) |
|||
| 6/4D-AH | 60 | Metal | Metal | 162-360 | 12-56 | 800-1550 | 65 | 5-8 | 5 |
Tobee® 6/4 D AH Slurry Pumps Applications:
The 6/4 D AH Slurry Pumps are widely used in the mining, coal washing, power plant, metallurgy, petrochemical, building material, dredging, and other industrial departments, etc.
Typical Application:
· Iron Ore Dressing Plant
· Copper Concentration Plant
· Gold Mine Concentration Plant
· Molybdenum Concentration Plant
· Potash Fertilizer Plant
· Other Mineral Processing Plants
· Alumina Industry
· Coal Washery
· Power Plant
· Sand Excavation
· Building Material Industry
· Chemical Industry
· Other industries
