China UTM Smart Positioner

Utmost U529 series smart valve positioner adopts the newest advanced micro processing and intelligent measurement and control technology, based on 3 / 3 slide nozzle baffle valve and solenoid valve technology, with single and double-acting, Hart, remote transmission, flameproof, explosion-proof function, developed by China valve oem intelligent positioner and the United States R&D team, verified under the harsh operation conditions, has achieved good performance.

UTM Smart Positioner Features

Single/Double acting;

Greatly enhanced the instrument air adaptability and anti-fouling ability(water, dust, and oil), with Nozzle baffle I/P structure;

Smart positioner flow characteristics can be free setting (linear, quick opening, equal percentage,) and easy to control;

Safe, reliable, practical with equipped with a built-in LCD screen and integrated debugging button;

Fast self-diagnosis (2-3 minutes to complete the whole stroke);

Digital valve positioner, limit switches, and other internal electrical modules can be integrated;

Easily remote for smart positioner for control valve checking and diagnosis with Hart communication module;

High adjustment precision, can realize the accuracy of 0.1% intelligent valve control with intelligent control algorithm;

Three valve termination and three fault reset functions can be achieved;

Low power consumption (25L/h I/P low power consumption, low air consumption: locator);

Data backup and storage functions, effectively solve the problem of online replacement, debugging;

Meet IEC534 (NAMUR).

Item U529N/I U529D

Explosion-proof Without Ex protection or explosion protection "ia" Explosion Protection

Input Signal 4-20 mA

Inlet air pressure 0.14~0.6Mpa(G)

Stroke Linear: 10~150mm

Angle: 0~120°

Control Accuracy ± 0.2% F.S.

Hysteresis ± 0.2% F.S.

Repeatability ± 0.2% F.S

Impedance Max. 460Ω/20 mA(DC)

Output characteristic Linear, ON/OFF, Equal percentage or User defined

Air Consumption Stable gas consumption 25L/h

Connections Pneumatic 1/4NPT or G1/4

Electrical 1/2NPT

Ambient temperature -40~80℃

Housing Material Aluminum or Stainless steel

Weight, basic device About 2.0Kg About 3.6 Kg

If you want to know more about smart positioner price, please contact us.

As one of control valve manufacturers china, we will do our best to meet all the needs of customers.

We also have sorts of pneumatic butterfly valve for sale, anything you need, please leave us a message.
