Four-Point Contact Ball Bearings
Product Quick Detail
- FOB Price
- USD $10.00 / Piece
- Place Of Origin
- China
- Minimum Order
- 30000
- Packaging
- N/A
- Delivery
- 30 Days
Specifications
Four point contact ball bearings are radial single row angular contact ball bearings with raceways that are designed to support axial loads in both directions. For a given axial load, a limited
radial load can also be supported (Load ratio). The bearings are separable, i.e. the outer ring with ball and cage assembly can be mounted separately from the two inner ring halves.
Both inner ring halves of VXO Explorer four point contact bearings have a recessed shoulder. This improves oil flow when the bearing is used in combination with an VXO cylindrical roller bearing
(fig. 1). In addition, these recesses can be used to facilitate dismounting.
Features of 4 point contact ball bearing
Accommodates axial loads in both directions
Less axial space
These bearings take up considerably less axial space than double row bearings.
High load carrying capacity
A large number of balls are incorporated, giving the bearing its high load carrying capacity.
Separable design
The split inner ring leads to easier mounting and dismounting of the bearing.
Improved oil flow
Limited inner ring deformation when subjected to high clamping forces
Specification of Four-Point Contact Ball Bearings
Dimensions Basic load rating
Designations(seals) d D B C C0
3200 A-2RS1 10 30 14,3 7.3056 4.128
3201 A-2RS1 12 32 15,9 9.696 5.376
3202 A-2RS1 15 35 15,9 10.752 6.528
3302 A-2RS1 15 42 19 14.496 8.928
3203 A-2RS1 17 40 17,5 13.728 8.448
3303 A-2RS1 17 47 22,2 20.736 12.192
E2.3204 A-2Z 20 47 20,6 19.2 11.52
*3204 A-2RS1 20 47 20,6 19.2 11.52
E2.3304 A-2Z 20 52 22,2 22.656 14.016
*3304 A-2RS1 20 52 22,2 22.656 14.016
E2.3205 A-2Z 25 52 20,6 20.736 13.728
*3205 A-2RS1 25 52 20,6 20.736 13.728
E2.3305 A-2Z 25 62 25,4 30.72 19.584
*3305 A-2RS1 30 62 25,4 30.72 19.584
E2.3206 A-2Z 30 62 23,8 28.8 19.584
*3206 A-2RS1 30 62 23,8 27.456 19.584
E2.3306 A-2Z 30 72 30,2 39.84 26.4
*3306 A-2RS1 30 72 30,2 39.84 26.4
E2.3207 A-2Z 35 72 27 38.4 26.88
*3207 A-2RS1 35 72 27 38.4 26.88
E2.3307 A-2Z 35 80 34,9 49.92 34.08
*3307 A-2RS1 35 80 34,9 49.92 34.08
E2.3208 A-2Z 40 80 30,2 45.6 32.64
*3208 A-2RS1 40 80 30,2 45.6 32.64
E2.3308 A-2Z 40 90 36,5 61.44 42.24
*3308 A-2RS1 40 90 36,5 61.44 42.24
E2.3209 A-2Z 45 85 30,2 48.96 37.44
*3209 A-2RS1 45 85 30,2 48.96 37.44
E2.3309 A-2Z 45 100 39,7 72 50.88
*3309 A-2RS1 45 100 39,7 72 50.88
E2.3310 A-2Z 50 110 44,4 86.4 61.44
*3310 A-2RS1 50 110 44,4 86.4 61.44
E2.3211 A-2Z 55 100 33,3 57.6 45.6
*3211 A-2RS1 55 100 33,3 57.6 45.6
E2.3311 A-2Z 55 120 49,2 107.52 78.24
*3311 A-2RS1 55 120 49,2 107.52 78.24
E2.3212 A-2Z 60 110 36,5 70.56 56.16
*3212 A-2RS1 60 110 36,5 70.56 56.16
E2.3312 A-2Z 60 130 54 121.92 91.2
*3312 A-2Z 60 130 54 121.92 91.2
3212 A-2RS1 65 120 38,1 77.376 70.56
*3313 A-2Z 65 140 58,7 140.16 105.6
3214 A-2Z 70 125 39,7 84.864 76.8
*3314 A-2Z 70 150 63,5 156.48 120
3215 A-2Z 75 130 41,3 91.776 84.48
*3315 A-2Z 75 160 68,3 168.96 134.4
As a linear motion manufacturer, we can offer kinds of linear motion systems parts for sale, if you are interested, please leave us a message.
