100G CFP2 Single Mode Transceiver
Product Quick Detail
- Place Of Origin
- Huangpu District, Guangzhou
- Minimum Order
- 1
- Packaging
- carton
- Delivery
- a week
Specifications
Designed for 100G Ethernet and OTN OTU4 links over duplex single-mode fibers, the Sintai 100g cfp2 transceiver support transmission distance up to 10km using LWDM wavelengths (1295.56nm, 1300.05nm,
1304.58nm, 1309.14nm).
100G CFP2 Single Mode Transceiver Feature
Adopt CFP2 hot-swappable encapsulation with LC interface for Single mode.
Single mode uses 4 x 28Gb/s laser.
Support an overall rate of 103.1Gb/s and 112Gb/s.
Support network applications such as 100G Ethernet and OTU4.
Single-mode optical fiber supports a transmission distance of up to 10km.
Built-in DDM (digital diagnostic monitoring function).
Working temperature: 0°C ~ +70°C.
Comply with RoHS standards.
100G CFP2 Single Mode Transceiver Overview
The sfp 100g CFP2optical communication module launched by Sintai Communication Co., Ltd. is designed for the high density of 100G Ethernet and optical transport network (OTN) applications and, and
it contains the 100GBASE-SR10 and 100GBASE-LR4 and supports an overall rate of 103.1Gb/s and 112Gb/s, and it's compatible with IEEE802.3ba and CFP MSA standard.
The 100G CFP LR4 module is composed of 4X28G EML lasers and PIN receivers, and it uses the wavelength division multiplexing technology to multiplex 4-channel different wavelengths on a single fiber
for the transmission, with the longest transmission distance of 10km.
As a professional qsfp transceiver supplier, we provide optical communication devices, dwdm transponder, cfp2 optical transceiver, 100g single mode fiber, optical amplifier and etc. For more
information, please feel free to contact us!
