CR123A Li-MnO2 Cylindrical Battery

Place Of Origin
Wuhan, China
Minimum Order
1000
Packaging
Special design for Air/Sea/Courier transportation
Delivery
10 - 35 working days


Excellent Performance Non-rechargeable NB IOT LORA GSM 3 Volt 1500mAh Spiral CR123A Lithium Manganese Dioxide Batteries for Water Meter, Smoke Detectors, Camera Video Camera Timer, NB-IoT Meter and Sensor, smoke detector, smoke alarm

Details of CR123A Li-MnO2 Cylindrical Battery

Product Details of CR123A Li-MnO2 Cylindrical Battery
Place of Origin Hubei Wuhan
Brand Name HCB
Certification UN/CE/UL
Model Number CR123A

Payment & Shipping Terms Details of CR123A Li-MnO2 Cylindrical Battery
Minimum Order Quantity 1K pcs
Price negotiable
Packaging Details Special design for Air/Sea/Courier transportation
Delivery Time 35 workdays
Payment Terms T/T, L/C
Supply Ability two million units per month

Advantage of CR123A Li-MnO2 Cylindrical Battery

High voltage response, stable during most of the lifetime of the application.

Energy density for Li-MnO2 primary battery up to 830wh/L.

Wide operating temperature range (-40℃~+85℃).

Low self-discharge rate (less than 1% per year after 1 year of storage at +25℃).

Specification of CR123A Li-MnO2 Cylindrical Battery
Electrical characteristics Open circuit voltage (at 23±2°C) ≥3.10V
Nominal capacity 1600mAh
(At +25°C, the battery is discharged at continuous current 1mA until the voltage reaches cut-off voltage 2.0V. The capacity can vary at a different temperature, discharge current or cut-off voltage.)
Maximum continuous current 1500mA
(At +25°C, 2.0V cut-off, battery discharged for minimum 50% of rated capacity.)
Maximum pulse discharge current 3000mA
(At +25°C, 2.0V cut-off, battery discharged for minimum 50% of rated capacity with max pulse for 3 seconds after 27 seconds break. The discharged capacity may vary according to the pulse characteristics, the temperature, and the cell’s previous history. Fitting the cell with a capacitor may be recommended in severe conditions. Consult HCB.)
Storage (recommended) ≤+30°C
(For more severe conditions, consult HCB) ≤75%RH
Operating temperature range -40°C~+85°C
(Operation above ambient temperature may lead to reduced
capacity and lower voltage readings at the beginning of pulses, consult HCB.)
Physical characteristics Width 16.6±0.2mm
Height 34.5 +0.0/-1.0mm
Typical weight 20.0g
Li metal content 0.54g

Main Applications of CR123A Li-MnO2 Cylindrical Battery

Telecommunications

Wireless telecommunication devices.

Electrical equipment

Wireless electric power tools, computer RAM & COMS, UPS, CNC machine tools, (TPMS), camera, video camera, timer, calculator, electric toys, lighting equipment, etc.

Medical devices

Cardiac pacemaker, respirator, oxygenator, inspection devices, monitoring devices, infusion pump, etc.

If you want to know more details of cr123a battery specs and cr123a discharge curve,please visit our website.

As a lithium battery china manufacturer, we will do our best to meet all the needs of customers.
