Tobee® 45kw Electric CV-Driven 6x4D-AH slurry pumps
Product Quick Detail
- FOB Price
- USD $4,500.00 / Piece
- Place Of Origin
- 中国
- Seal Arrangement
- Mechanical seal
- Minimum Order
- 1
- Pump Model
- 6x4D-AH
- Color
- customizable
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Tobee® 6x4D-AH Slurry Pump
SPECIFICATIONS:
Size: 6" x 4" Capacity: 162-360m3/h Head: 12-56m Speed: 800-1550rpm NPSHr: 5-8m Eff.: 65% Power: Max.60kw Handling solids: 44mm Seal arrangement: Packing seal, Expeller seal, Mechanical seal
6x4D-AH Slurry Pump
Design Features:
√ Cylindrical structure of bearing assembly: convenient to adjust the space between impeller and front liner and can be removed completely.
√ Interchangeable anti-abrasive wet parts made of high-chrome alloys.
√ The discharge branch can be oriented to any eight positions at the interval of 45 degrees.
√ Various drive types: DC (direct connection), V-belt drive, gear box reducer, hydraulic couplings, VFD, SCR control etc.
√ The shaft seal uses the packing seal, expeller seal and mechanical seal.
Tobee®
| Model |
Max. Power
(kw) |
Materials | Clear Water Performance |
Impeller
Vane No. |
|||||
| Liner | Impeller |
Capacity Q
(m3/h) |
Head H
(m) |
Speed n
(rpm) |
Eff. η
(%) |
NPSH
(m) |
|||
| 6/4D-AH | 60 | Metal | Metal | 162-360 | 12-56 | 800-1550 | 65 | 5-8 | 5 |
