AM-OLED

Leadtek developed the PCBA for converting signals from EDP/LVDS/RGB/MIPI to HDMI or HDMI+VGA, we also support displays with SSD1963. To know more information, welcome to send us inquiries.

Types of TFT Modules Accessories

2.4 Inch with CTP 240*320 Resolution with SPI Interface IPS TFT LCM

LTK024H4021B-QC is a monochrome OLED display module with 240*320 dot matrix. The characteristics of this display module are high brightness, self-emission, high contrast ratio, slim/thin outline, wide ...

2.8 Inch LCD with 240*3RGB*320 8bit MCU 4line SPI Interface Display

This specification applies to the LCD module that is supplied by LEADTEK COMPANY LIMITED LCD specification: Dots 240xRGBx320. As to basic specification of the driver IC, refer to the IC (Sitronix:ST77...

5.0 Inch Module 720*1280 with MIPI Interface TFT LCD Display

LTK050H3123W color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel and a driving ...

TFT LCD Interface Board

1. FPC Pin:40/50 2. LCD Interface:SPI+RGB,RGB,MPU,MIPI,LVDS 3. Input Voltage:DC+12V 4. HDMI (CVBS & VGA) Video Signal Input 5. OPERATING TEMP: -10°C TO 60°C STORAGE TEMP: -20°C TO 70°C 6. For Industrial control,video intercom, automobiles medical...

5.0 Inch 800*480 TFT LCD with RGB Interface Normally Black Display

LTK050WV40HY is a transmissive type color active matrix TFT(Thin Film Transistor) liquid crystal display(LCD) that uses amorphous silicon TFT as a switching device. This module is composed of a TFT LC...

7.0 Inch TFT LCM 800*480 with CTP RGB Interface Transmissive Panel

LTK070WV50CYW-CT is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT display panel and a...

7.0 Inch LCD Module 800*480 with CTP RGB Interface TN Panel

LTK700WV01B-CT is a transmissive type color active matrix TFT(Thin Film Transistor)liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This module is composed of a TFT ...

4.3 Inch TFT LCM 480(RGB)*272 RGB Interface IPS Panel

LTK043B4558C is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel and a d...

3.97 Inch TFT LCM 480(RGB)*800 2-lane MIPI DSI Interface

LTK400WV13A-CT is supplied by LEADTEK COMPANY LIMITED LCD specification: Dots 480(RGB)*800. As to basic specification of the driver IC, refer to the IC specification and data book. All material & ...

Features Of TFT Modules With Pcba

The display is driven with parallel signals. Those signals must feed the circuitry all at the same time to avoid flickering or any other kind of artifact. So it's important that the tracks match in length each other in order to have the same traveling time. The clock signal line only has to be a little bit longer to guarantee that all the other signals are stable at the right value when the clock triggers the frame. As a custom lcd display manufacturer, Leadtek developed the PCBA for converting signals from EDP/LVDS/RGB/MIPI to HDMI or HDMI+VGA, we also support displays with SSD1963. To know more information, welcome to send us inquiries.
