KU-BAND AIRBORNE TERMINAL
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
KU Band Terminal
Cowave Airborne SATCOM terminal can be installed on various kinds of planes to provide remote control functions and communication traffic channels for the carrier.
This terminal has the characteristics of simple structure and easy installation. Video data transmission, remote sensing data backhaul, and other communication services are available by receiving
control signals from the system control center. It can solve common problems such as remote control and broadband data transmission in UAV applications.
Specification of VAST KU Airborne Terminal
DIMENSION (DIAMETER X HEIGHT) 945mm × 260mm
• WEIGHT 41kg
• ANTENNA APERTURE 0.45m
• POLARIZATION MODE Linear polarization
• RECEIVING G/T 12.1dBi@12.75GHz
• SENDING EIRP 48.4dBi@14.25GHz
• XPI ≥25dB
• TRACKING ACCURACY 0.2°RMS
• AZIMUTH ROTATION 360°
• PITCH ROTATION 0 ~ 90°
• HORIZONTAL ROLLING ROTATION -30°~ 30°
• AZIMUTH PITCH SPEED/ ACCELERATION ＞60°/s，200°/s²
• ALTITUDE 16800m
• WORKING FREQUENCY Sending: 14GHz ~ 14.5GHz, Receiving: 12.25GHz ~ 12.75GHz
• BUC POWER 120W
• SUPPORT SERVICES Control Data, Video Data, Remote Sensing Data
• DATA RATE 16Kbps ~ 2Mbps
• MODULATION QPSK
• CODING LDPC
• DATA INTERFACE RJ45, Wi-Fi
• DATA SECURITY (OPTIONAL) AES data encryption, RSA Key exchange
• OPERATING TEMPERATURE -40℃ ~ +55℃
• EXTERNAL POWER SUPPLY 24V DC 24V DC
Features of Ku Band Modem Airborne Terminal
01
Simple structure and convenient installation— with antenna, modem, and other parts integrated inside of the radome, it is easy to install
02
General external interface— universal external interface, suitable for a variety of services for voice, video, and data transmission
03
Anti-rotor shielding ability, good communication effect— can prevent the signal intensity risk from the rotor shielding to keep the stable communication connection
Ku-Band Airborne Terminal Gallery
The antenna can dynamically adjust its azimuth and pitch to accurately aiming the satellite during high-speed flight.
Now the price of ku band vsat equipment is low, anything you need, please leave us a message.
As one of the VSAT China satellite service providers, our main products of the company include portable SATCOM terminals, vehicle SATCOM terminals, shipborne SATCOM terminals, airborne SATCOM
terminals, satellite routers, SATCOM network management systems, etc., forming a complete set of SATCOM systems.
If you want to know more kinds of mobile satellite service terminal, please visit our website.
