Blockout Tarpaulin

Blockout tarpaulin china is PVC-coated polyester fabric with a black PVC layer in the middle. It is widely used to make tents and canopies. The black PVC layer can block sunlight efficiently. With acrylic lacquering, the blockout tarpaulin is easy to clean.

Blockout Tarpaulin Details

Item No: Descriptions Unit Your Product Measurements:

1 Material of the Woven Fabric DIN60001 Polyester

2 Weave DIN ISO 9354 Plain

3 Count of Yarn Warp: Denier 1000

Weft: Denier 1000

4 Setting/ Number of Threads Warp: Threads/cm 23

DIN EN 1049 Weft: Threads/cm 23

5 Base Coat PVC

6 Weight of the cloth DIN EN 12127 g/m² 200

7 Total Weight DIN EN ISO-2286-2 g/m² 850

8 Tensile Strength DIN 53354 Warp: N/5cm 3200

Weft: N/5cm 3000

9 Tear Resistance DIN 53363 Warp: N 320

Weft: N 300

10 Adhesion (Coating) DIN 53357 N/5cm 120

11 Adhesion (Welding) Kg/5cm 12

Blockout Tarpaulin Features

01

Mildew proof.

Heli's blockout tarpaulin is mildew-proof. It can be used in humid environments, such as in south Asia.

02

Smooth and easy to clean

As one of the professional PVC tarpaulin material suppliers in China, Heli uses knife coated machine to ensure our blockout tarpaulin is very smooth on both side and easy to clean

03

100% sunlight block

Heli's blockout vinyl tarpaulin has a thick black PVC layer in the the middle, it can block all sunlight.

What Weight Of The Blockout Tarpaulin Do You Make?

We normally make 540gsm (16oz), 610gsm (18oz), 750gsm ( 22oz) and 850gsm (25oz) blockout tarpaulin for our customers.
