⌈ Application range ⌋:Widely used in cement, silicate products, new building materials, refractory materials, fertilizers, black and non-ferrous metal dressing and glass ceramics and other production industries.
⌈ Applicable material ⌋:Used for fine grinding of raw materials such as feldspar, quartz, clay, ore.
Model | Volume(m³) | Maximum loading(t) | Capacity(t/h) | Rotational speed(r/min) | Motor power(kw) | Weight(t) |
TCQ910×1120 | 0.68 | 0.22 | 0.2 | 36 | 5.5-11 | 3 |
TCQ1200×1400 | 1.5 | 0.5 | 0.5 | 32 | 11-18.5 | 3.8 |
TCQ1500×1800 | 3 | 1.0 | 1 | 28 | 15-22 | 4.5 |
TCQ1800×2100 | 5 | 1.65 | 1.5 | 26 | 18.5-30 | 6 |
TCQ2100×2100 | 6.8 | 2.2 | 2.5 | 22 | 22-37 | 7.4 |
TCQ2200×2400 | 8.5 | 2.8 | 3 | 20 | 28-45 | 8.2 |
TCQ2500×2900 | 13.2 | 4.4 | 5 | 16 | 37-55 | 9.3 |
TCQ2800×3700 | 21.2 | 7.0 | 8 | 14.5 | 55-75 | 12.5 |
TCQ3000×3700 | 24.3 | 8.0 | 10 | 14 | 75-90 | 18.6 |
Dry ball mill is suitable for all kinds of metal and nonmetal ores, including materials that will react with water, such as cement, marble, and other building stones, or products that require storage and sales in the form of powder. In addition,among all ball grinding machine, ...
Wet Grid Ball Mill Wet ball mill is a kind of energy-saving industrial grinding mill which adopts rolling bearings and has high efficiency. Wet grid ball mill mining processing capacity can reach 160 tons per hour. It usually grinds coarser ores. Instruction of Wet Ball Mill ...
In recent years, with the continuous development of grinding technology, wet grinding has become the mainstream process, overflow type ball mill is the most widely used equipment in wet grinding. Overflow ball mill is mainly used for wet ball mill. In the grinding process, raw ...
