*About Changzhou Fanqun CT-C Hot Air Circle Oven

Summary

CT-C hot air circle oven is equipped with low noise axial flow fan and automatic temperature control system. The circle system is fully sealed. It makes the hot efficiency increased from 3-7% of traditional oven to 35-45%. The maximum hot efficiency can be 50%. The successful design of CT-C series hot air circle oven makes the hot air circle oven catch up the advanced level both at home and abroad. It makes China save plenty of energy source and increase profit of enterprises. This model of the industrial standard RXH issued in 1990 by State Administration Bureau of Medicines.

Features

1. Most of hot air is circled inside the oven. The hot efficiency is high. The energy source can be saved.

2. It uses enhanced ventilation and equips with adjustable air divider plate inside the oven. Raw material can be dried evenly. The hot source can be steam, hot water, electricity or far infrared.

3. The machine has low noise and stable operation. The temperature can be controlled automatically. The installation and maintenance are very convenient.

4. The applied fields are wide and can be suitable for all kinds of raw materials. It is a comprehensive drier.

Application

It is suitable for heating and solidification, drying and dehydration of raw materials in pharmaceutical industry, chemical industry, foodstuff industry, agricultural and sideline products, aquatic products, light industry, heavy industry and so on. The raw materials can be medicine of raw materials, Chinese traditional medicine, and tablet of drink, immersed electuary, powder, granule, packing bottle, pigment, dyestuff, dehydration vegetable, dried fruit and melons, banger, plastic resin, electric elements, drying varnish and so on.

Main Technical Parameters and Relevant Explanation:

1. The hot source can be steam, electricity, far infrared, or steam+electricity. Customer can select one of the heat ways in accordance with practical conditions.

2. Temperature of operation: 50-140℃ for steam, Maximum temperature will be 150℃.

3. 50-3500C for electricity or far infrared.

4. There are automatic and computer control systems for customer selection.

5. The normal pressure of steam will be 0.02-0.8 MPa(0.2-8kg/cm2).

6. The equipped power of electric heater will be 15kw calculated with Model 1 and the operational power to be used will be 5-8kw/he.

7. If have special requirement, please indicate it in order.

8. The price of non-standard oven shall be discussed additionally.

9. If the operation temperature is more than 140℃ or less than 60℃ , please indicate it in order.

10. The size of drying trolley and tray is standardized. The can be exchanded each other.

11. The size of drying tray: 460*640*45.

*About Changzhou Fanqun Belt Dryer

Changzhou Fanqun Belt Dryer is designed for uniform drying, heat source flexibility, and operating efficiency. Belt dryer is available in a variety of conveying configurations. The continuous belt dryer can be configured to run at the same temperature or with sequential heat zones allowing precise control over critical drying parameters of temperature, process air humidity and airflow throughout the process.

While using the raw material should be distributed on the conveyer belt through suitable machanism such as star distributor, swing belt, crusher or granulator. The conveyer passes through the channel consisting of one or several heating unit.
